Quoted from Joe Minton:
Carburetors work by creating a partial vacuum in the throat (venturi or choke) of the carb body. The difference in air pressure between the throat and the outside air causes fuel to flow into the carburetor through any orifice it can find. Tuning a carburetor consists of controlling the size of those orifices so that the resulting air/fuel mixtures are correct.
The Mikuni HSR is an Amal-pattern carburetor, as is the stock Keihin. Amal-pattern carburetors have three basic air/fuel control element
s: idle, main (mid-throttle) and the main jet. The HSR also has an adjustable accelerator pump, which I consider an important fourth tuning element. All tuning elements are supplied with fuel by the float bowl at the bottom of the carburetor.
The idle system is a separate carburetor built into the main body. There are appropriate connecting passages, a replaceable jet, and an adjustment screw. The screw controls the air/fuel mixture at dead idle. The jet controls mixture as the throttle begins to open. By about 10 percent throttle, the idle system is delivering all the fuel it can. It continues to provide this fuel all the way to full throttle.
The main system operates as the throttle slide is raised above about 5 percent, and it begins to deliver fuel and assumes control of the mixture. Yes, there is an overlap between the idle and main systems. However, it is not difficult to get this overlap area right if one follows the manual’s advice.
The main system consists of the throttle slide, a tapered needle (jet needle), and a needle jet. The needle is mounted in the center of the slide. The needle jet is mounted in the carb body. As the throttle slide rises and falls, the needle moves in the needle jet. The needle is tapered. The relative sizes of the needle and jet determine how much fuel is forced into the carburetor throat at any particular throttle setting. More fuel flows as the slide rises, due to the needle’s taper.
The main jet is mounted to the bottom of the needle jet and limits maximum fuel flow. It assumes control at about 75 percent of the throttle opening and has no effect until then.
The accelerator pump’s purpose is to supply a squirt of fuel when the throttle is suddenly opened and there is too little vacuum for the main system to work properly. It has a replaceable nozzle and can be adjusted for starting and ending points.
Advanced tuning is a bit involved as it is for any carburetor. The individual steps are simple and clear. The great advantage of Amal slide-type carburetors such as the Amals, Bings, Dell’Ortos, Mikunis, and others is that their entire operating range can be adjusted in the field. We have a four-step tuning procedure for these carburetors that has served well for more than 80 years.
Adjust the idle system. Set the adjustment screw for best idle. Fit the idle jet that gives the smoothest response as the throttle is slightly and slowly opened.
Adjust the main system. Accelerate with the throttle between 10-to-25 percent open. If the engine responds cleanly and briskly, the needle diameter is correct or nearly so. If the engine seems lean, a smaller-diameter needle is needed. Too rich needs a larger needle. In practice, needle changes are seldom required.
Accelerate in the 25-to-75-percent throttle range. The needle taper controls the mixture strength in this range. There are five needle-height adjustments. If the mixture seems rich, lower the needle; if lean, raise it.
Accelerate at full throttle. The main jet that makes the most power is the one to use. A dynamometer is not needed for this test. Accelerate between two points on the roadway. The highest speed at the second point defines the correct main jet.
As I said, the accelerator pump adds fuel when the throttle is first opened. This is to both richen the mixture for maximum throttle response and to compensate for low vacuum over the needle jet. The HSR pump has three adjustments: starting point, end point, and nozzle size. Nozzle size determines the fuel delivery rate and how long the squirt lasts.
The stock settings start the pump at about 1/8th throttle and end its stroke at around 1/2 throttle. The jet is a number 80 (0.80mm in diameter). I use and recommend different settings, which I’ll detail later.
This simple set of procedures works well and can remove most of the mystery from carburetor tuning.
Does Size Matter?
Yes and no. Those people who have worked with true Amal-pattern carburetors, which have round slides, know that the larger carburetors help make more high-rpm power by flowing more air. However, that greater power potential is accompanied by a loss of low-rpm throttle response.
The more recent flat-slide variations, such as the Mikuni HSR, greatly reduce this power/response trade-off. It is now possible to fit a “top end” carburetor and still get good throttle response in the lower rpm and throttle range.
A 42mm HSR42 adds about 3 horsepower to the output of a stock Twin Cam or EVO engine. The 45 adds 7 horsepower with no loss of part-throttle response, fuel mileage or tuning sensitivity.
The performance advantage of the 45mm carb means very little to most of us. Its power advantage only begins to show at well above 5,000 rpm. The HSR42 is easier to mount as it uses the stock manifold while the HSR45 needs the larger Harley Screamin’ Eagle or Mikuni manifold. It’s your choice. If you are chasing maximum power with cams, porting, etc., then your choice is obvious. Otherwise it makes no difference which one you choose.
The HSR48? Don’t bother. Our testing shows that the HSR48 only adds 2 or 3 top-end horsepower to an already powerful (120-plus horsepower) engines.
Mikuni’s default jetting and adjustments cover most engine setups, as they should. Tens of thousands have been sold with very few complaints about how well they work. However, the stock settings are fail-safes and are on the fuel rich side of ideal. I have no complaint about the stock tuning, except for the accelerator-pump settings, which I am convinced are just plain wrong.
I have developed a set of jets and adjustments for the HSR42 and 45 that work better on most properly tuned engines. By properly tuned I mean that the engine is sound, there are no long straight pipes, drag-race cams, or stylish air cleaners that don’t flow much air. Many hundreds of Harley owners have adopted my recommendations and have gotten excellent results. They report that throttle response is improved, fuel mileage is better, and their engines sound and seem “happier.” The changes I recommend include accelerator nozzle size and adjustments, idle jet size, and needle size.
Here is what I change and do:
•17.5 idle jet, leaner than the stock 25 or 20.
•98 needle, leaner than the stock 97.
•50 accelerator pump nozzle way down from the stock 80.
•The main jet is whatever it needs to be and the stock one is generally correct.
These parts are available individually or in kit form from Fox Distributing in St. Charles, Illinois, 630-513-9700.
The kit is called the Mikuni Mileage Kit and there are separate kits for the HSR42 and 45 carburetors because the needles are different. The kits come with simple installation and tuning instructions.
Adjustments (See The Manual For Details):
1. Adjust the accelerator starting point so that the pump starts working immediately. Adjust the end point for maximum travel.
2. Fit the smaller idle jet and adjust the mixture screw for best idle.
3. Fit the leaner needle with the clip in the middle notch.
1. Performance just off-idle is cleaner and more immediate. This is because the idle jet is more correct and the pump delivers fuel sooner but at a lower rate than stock.
2. The engine is more responsive, cleaner and “happier” sounding because of the leaner mixtures in the 10-to-25- percent throttle range, where we do most of our riding.
3. Fuel mileage increases, sometimes dramatically. Don’t be surprised if you record 48-to-49 mpg at 65 mph. Even baggers do better.
4. Midrange throttle response is greatly improved and the engine is much more pleasant to use. Expect bugs in your teeth.
1. Engines with high cranking pressures (high compression) may detonate at low rpm when accelerating. The original 97 needle should fix this.
2. Nothing, not this kit, not this carburetor, nor any carburetor, is going to make an engine suffering with open straight pipes run well.
3. Big cams, those with intake-closing angles of close to 50 degrees ATDC, aren’t going to run well below 4,000 rpm. No Mikuni or any other carburetor can fix this. Either race the thing or install a more appropriate cam for street use.
